Logosol SMART SET User Manual

26
Midi/ATO 10A
Midi/ATO 30A
Midi/ATO 10A
Midi/ATO 10A
Midi ISO 8820-5:25 32V 120A
2 x – M6
2 x
2 x – M6x20
2 x – M6
05-00004
When installing a rail extension on the log bed,
extension cable 05-00004 is required, 1 cable
extension per 2 extensions.
05-00004
Feed to Smart Set
Control Box
The machine has a number of fuses, some at the
top of the battery and four fuses on the upper part
of the component panel. Ampere and function are
shown in the illustration.
FUSES
CONNECTION EMERGENCY STOP AND CONTROL BOX
INSTALLING CONTROL CABLE
Hold circuit solenoid
Start circuit solenoid
Stop signal motor
Main fuse
