LONCIN 1P61FC - Specifications

SPECIFICATIONS
18
8. SPECIFICATIONS
The power rating of the engine indicated in this document is the net power output tested on a
production engine for the engine model and measured in accordance with SAE J1349 at 3,600
rpm (Net Power) and at 2,500 rpm (Max. Net Torque). Mass production engines may vary from
this value.
Actual power output for the engine installed in the final machine will vary depending on
numerous factors, including the operating speed of the engine in application, environmental
conditions, maintenance, and other variables.
Model
1P61FC
1P65FC
1P70F-2
1P70FC
Type
Single cylinder, 4-Stroke, Forced Air Cooling, OHV
Net. power(kW/3600rpm)
2.5
2.7
3.2
3.5
Net. torque (N·m/rpm)
7.0/2500
8.5/2500
9.0/2500
10.5/2500
Fuel consumption (g/kW·h)
≤395
Idle speed
2200±150 rpm
Bore X Stroke(mm)
61×48
65×48
70x45
70×51
Displacement(cc)
140
159
173
196
Compression Ratio
7.3:1
7.6:1
7.1:1
7.1:1
Lubricating mode
Splash
Starting Mode
Recoil start
Rotation
Anti-clockwise(from P.T.O. side)
Valve Clearance
input valve： 0.10-0.15mm, output valve：0.15-0.20mm
Spark plug clearance
0.7~0.8mm
Igniting Mode
Transistorized magneto Ignition
Air cleaner
Semi-dry, Oil bath, Foam filter
Dimension(L×W×H)(mm)
371×338×275
379×358×278
385×358×278
Net weight (kg)
11.7
11.8
12.0
12.8
