CONTENTS / SAFETY INSTRUCTIONS
16
Keep these operating instructions within reach to be able to refer to
them at any time.
These operating instructions are part of the engine/the machine
powered by the engine and must be passed on together with the
engine/machine in the event of selling the equipment.
The information and instructions published here were valid at the
time of printing.
READ THESE OPERATING INSTRUCTIONS CAREFULLY. Pay
attention especially to the following symbols and instructions:
Alerts to risk of serious injury or
death if these instructions are not
followed.
Alerts to potential risk of serious
injury or death if these instructions
are not followed.
Alerts to potential risk of light
injuries if these instructions are not
followed.
Alerts to possible damage of
engine, machine or property if these
instructions are not followed.
Provides you with useful
information.
Please contact customer service if a problem occurs with your
engine or you if you have any other questions.
CONTENT
1. Safety advices 16
2. Arrangement of components and operating
elements
17
3. Operating elements 18
4. Checks before starting 18
5. Operation 19
6. Maintenance 21
7. Storage 26
8. Transport 27
9. Troubleshooting 28
10. Technical information 29
11. Technical specifications 30
12. Wiring diagram 30
1. SAFETY ADVICES
IMPORTANT SAFETY INFORMATION
Most accidents with engines can be avoided when following all
directions in these instructions and on the engine. The dangers
most frequently occurring and the corresponding protective
measures are described below.
Responsibility of the owner
z The engine ensures safe and reliable functioning when
operated according to the instructions. Read these
instructions before starting the engine. Disregarding these
instructions may result in personal injuries or property
damage.
z Familiarize yourself with the quick shut-down of the engine as
well as the operation of the control functions. Do not allow
persons who have not yet received proper instructions to
operate the engine.
z Do not allow children to operate the machine. Keep children
and pets away from the operating area.
Care when fuelling!
Gasoline/petrol is extremely flammable and generates explosive
vapours. Fuel outdoors in a well ventilated area when the machine
is not running. Never smoke and keep other sources of ignition
away. Always store gasoline in a suitable container. If gasoline is
spilled make sure that the spot is dry before starting the engine.
Hot silencer
z The silencer becomes very hot during operation and remains
hot even after stopping the engine. Take care not to touch the
silencer while hot. Allow the engine to cool before storing it
inside.
z To prevent the risk of fire and to ensure adequate ventilation
during stationary operation place the engine at a distance of
at least 1 metre from walls or other objects while operating it.
Do not store any flammable objects near the machine.
Carbon monoxide hazard
Exhaust gases contain toxic carbon monoxide. Avoid breathing
exhaust gases. Never operate the engine in a closed garage or any
other enclosed area.
Other equipment
Read the operating instructions of the machine which is powered
by the engine once more; learn about additional safety measures
which need to be followed in connection with starting, operating
and stopping the engine or any protective equipment that may
possibly be required to operate the machine.
