LONGER WT600-1F - Dispensing Volume; Flow Rates; Pause Time; Calibration

9
10
Flow: 2.043mL/min
Pause T. ：1.0 "
Pause Time ：
1.1 "
Flowrate
Dispensing
Test T.： 0.5 ’
Cal Vol ：132.3μL
Run Time ：30"
Act. Vol ：132.3μL
1.System Setting
2.Control Mode
3.Disp Setting
4.Calibration
1.System Setting
2.Control Mode
3.Disp Setting
4.Calibration
1.System Setting
2.Control Mode
3.Disp Setting
4.Calibration
Flow: 2.043mL/min
Pause T. ：1.0 "
Flow: 2.043mL/min
Pause T. ：1.0 "
Test T.： 0.5 ’
Cal Vol ：132.3μL
Test T. ： 0.5 ’
Cal Vol ：132.3μL
Test T. ：30"
Cal Vol ：133.0μL
Flow rates: Adjusting the dispensing flow rates can change the dispensing time.
Press and turn Knob to highlight dispensing flow rates line. Press Knob to enter
next inter face, turn Knob to select suitable flow rates, press Knob for
confirmation. Press Exit Key to return to previous menu.
Press
Knob
Pause Time: Time Interval between every dispensing operation.
Press and turn Knob to highlight pause time line. Press Knob to enter next
interface. Turn Knob to select pause time, press Knob for confirmation. Press
Exit Key to return to previous menu.
Calibration
Pump should be calibrated when flow rates or dispense volume is beyond the
tolerance. Flow rates and dispensing volume can be calibrated separately in
different applications.
Flow Rates Calibration
Press and turn Knob to highlight calibration line. Press Knob to enter next
interface. Turn Knob to select Flowrate. Press Knob to highlight test time line.
Press Knob again to highlight the value of time. Turn Knob to select test time
(its range is from 30 to 1800 seconds), press Knob for confirmation. Press
Exit Key to return to previous menu.
Press Start/Stop Key, the LCD displays running time and actual volume.
Running time counts down.
Turn Knob to input actual test volume. Press Knob for confirmation. The
calibration operation can be repeated.
Turn Knob to input
Actual Volume
If the actual volume is known in advance, enter the calibration interface and
input the actual volume directly.
Disp Vol ：2.02mL
Disp T. ：60.5"
Disp T. ：60.5"
Act Vol ：2.020 mL
Act Vol ：
2.02 mL
1.System Setting
2.Control Mode
3.Disp Setting
4.Calibration
Flowrate
Dispensing
Test T. ： 0.5 ’
Cal Vol ：132.3 μL
Test T. ： 0.5 ’
Cal Vol ：132.3 μL
Act Vol ：
133.0 μL
Flowrate
Dispensing
Disp T. ：60.5"
Act Vol ：2.040 mL
1.System Setting
2.Control Mode
3.Disp Setting
4.Calibration
Flowrate
Dispensing
Disp Vol ：2.02mL
Disp T. ：60.5"
If the actual volume is known in advance, enter the calibration interface and
input the actual volume directly.
Turn Knob to input
Actual Volume
Dispensing Volume Calibration
The parameters can not be changed under dispensing volume calibration
operation. The defaulted parameters are the parameters set under Dispensing
Setting.
Pump stops under dispense mode, press and turn Knob to highlight calibration
line. Press Knob to enter next interface. Turn Knob to select Dispense.
Press Start/Stop Key, the LCD displays running time and actual volume.
Running time counts down.
Turn Knob to input actual volume. Press Knob for confirmation.
Turn Knob to input
actual volume
Turn Knob to input
actual volume
WT600-1F OPERATING MANUAL
WT600-1F OPERATING MANUAL
