11
6. The Battery pack
7.1 Operation
An automatic charger for 12 V lead-gel battery is supplied.
• Connect the charger to a power socket (100-240 V~/50Hz–60Hz).
• Connect the output line of the charger with the battery to be charged.
• Check whether the charge display (LED) lights red.
•A green lighting LED shows that the battery is fully charged.
• Disconnect the charger from the socket.
• Disconnect the battery from the charger.
•Avoid short-circuits
– Do not short-circuit the Speakon-cable. This will destroy the FKS-fuses.
• Keep away from fire
– Do not expose the battery to fire or burn it. The battery might explode.
6.5 Technical Data
Model Lead-gel battery
Output voltage 12 V / 12Ah
Temperature range 40° F to 115° F
Dimensions 22 x 10 x 11.5 cm
Weight 4.5 kg
7. The Charger
