3. Description of the parts
5: · Fluid tube
6: · Battery connector (Speakon)
7: · Screws (thumb screw)
8: · Quick-connector for fluid tube
9: · Fluid tank
· Adjusting knob
· LED/Battery status display
· Socket for battery plug
· 3pin-XLR-socket
10:
11:
12:
13:
1: · Start button
2: · Fog nozzle
3: · Socket for charger
4: · Battery pack
(Battery with housing,
PCB, fuse and connector)
1
2
3
4
5
6
7
8
9
10
11
12
13
