This product is manufactured conform to the current EMC
standard. Please notice following items:
 The unit is for welding under commercial or industrial con-
ditions (CISPR 11 class A). The use in other surroundings
(for example in residential areas) may disturb other electric
devices.
 During welding electromagnetic problems can be caused
at:
– Mainscables, controlcables, connections for telecom-
munication
– TV/Radio
– Computer and other similar devices
– Protection devises as for example alarm systems
– Pacemakers and hearing aids
– Devices for measure and calibrate
– Devices with less protection against disturbances
If other devices are disturbed it may be necessary to pro-
tect additionally.
 The affected area can be bigger than your premises/pro-
perty depends of the building etc.
Please use the unit conform to the instructions of the manu-
facturer. The user is responsible for installation and use of the
machine. Furthermore the user is responsible to eliminate the
disturbances caused by electromagnetic fields.
6 Electromagnetic compatibility (EMC)
7 Technical data
type M 2020 M 2040 M 2060
M 2070
CuSi
M 2080 M 2090 M 2095
welding range A/V 30-140/
15,5-21
25-170/
15,2-22,5
25-210/
15,2-24,5
15-150 /
14,8-21,5
30-230/
15,5-25,5
30-290/
15,5-28,5
25-350/
15,3-31,5
no load voltage
(max.)
V 36,8 34,9 36,9 27,5 32,6 37,2 42
voltage adjustment Stufen 6 6 6 7 7 12 24
duty cycle at max.
power (25
°C/
40
°C)
% 25/15 25/15 25/15 -/40 30/20 30/20 30/20
Welding current at
100 % duty cycle
(25 °C/40 °C)
A 70/55 90/70 105/85 -/100 140/115 160/135 185/160
weldable wire steel mm Ø 0,6-0,8 0,6-0,8 0,6-1,0 0,6-0,8 0,6-1,0 0,6-1,2 0,6-1,6
weldable wires:
CuSi3
mm Ø - - - 0,8-1,0 - - -
weldable wire alu mm Ø 1,0 1,0 1,0-1,2 1 1,0-1,2 1,0-1,2 1,0-1,6
wire-feed speed m/min 1-23 1-23 1-23 1 - 23 1-23 1-25 1-25
mains voltage V 1~ 230 1~ 230/
2~ 400
1~ 230/
2~ 400
3~ 400 3~ 400 3~ 400 3~ 400
mains frequency Hz 50/60 50/60 50/60 50/60 50/60 50/60 50/60
mains fuse tr/C 16 16 16 10 16 16 25
mains current input
(max.)
A 16,3 16,4 21,6 6,5 9,8 15,6 21,5
input power (max.) kVA 3,7 5,2 6,4 4,5 6,8 10,8 14,9
power factor cos ϕ 0,85/140 A 0,84/170 A 0,89/210 A 0,89/150 A 0,89/230 A 0,89/290 A 0,89/350 A
cooling method F F F F F F F
insulation class F F F F F F F
protection class
(IEC
529)
IP 23 IP 23 IP 23 IP 23 IP 23 IP 23 IP 23
dimensions,
approx. (LxWxH)
mm 870x390x610 870x390x610 870x390x610 870x390x610 870x390x610 870x390x610 870x390x610
weight kg 47 51 55 66 57 67 94
torch type ML1500 ML1500 ML1500 ML 1500
CuSi
ML2500 ML2500 ML3600
standard EN 60974-1 EN 60974-1 EN 60974-1 EN 60974-1 EN 60974-1 EN 60974-1 EN 60974-1
order number 2 rolls 202.2020.1 202.2040.1 202.2060.1 202.2070.1 202.2080.1 - -
order number 4 rolls - - 202.2061.4 202.2071.4 202.2081.4 202.2090.1 202.2095.1
