Diagramme de connexion
Max Input Voltage Voc 50 V DC
Output max 50V PWM 3-phase
Enclosure IP 68 / NEMA 6P
Model PS2-100 07-000550
Only connect equipment provided by the
original manufacturer to this device
Solar  Pump Controller
A.1A.2
Sonde de
puits
Interrupteur
de réservoir
plein
Unité de
pompe
Modules
PV
Indicateur
LED
Interrupteur
marche /arrêt
Connexion moteur
Entrée solaire (PV)
Interrupteur de réservoir
plein (optionnel) - A2
Protection contre le fonc-
tionnement à sec
(optionnel) - A1
