Connection diagram
Max Input Voltage Voc 50 V DC
Output max 50V PWM 3-phase
Enclosure IP 68 / NEMA 6P
Model PS2-100 07-000550
Only connect equipment provided by the
original manufacturer to this device
Solar Pump Controller
A.1A.2
well
probe
tank full
switch
PV
modules
pump
unit
Indicator
LEDs
On/o
switch
Motor connection
Solar (PV) input
Tank full switch
(optional) - A2
Dry run protection
(optional) - A1
