Camera Overview
1
2
3
4
5
FRONT
BACK
9
8
7
6
1. Warning light
2. Status indicator
3. Microphone
4. Light sensor
5. Speaker
6. Power port
7. Threaded insert (for mounting)
8. Pairing / reset button
9. Bottom cover
6
