Lorex L4248 Series Quick Start Guide

Camera Overview
7. Fastener
8. Pairing button
9. $GMXVWPHQWULQJ
10. Battery release
tabs (x2)
11. Mounting plate
slots (x2)
1. Detachable
antenna
2. Warning light
3. PIR sensor
4. Locking screw
5. Power port
6. Battery
charging
indicator
SIDE
FRONT
BOTTOM BACK MOUNTING PLATE
7
1
8
2
3
9
4
5
11
10
6
3
Dimensions
• Height: 4.8” (121mm)
• Width: 5.2” (131mm)
• Length: 2.9” (73mm)
L4248-Series_QSG_TRILINGUAL_R1.indd 7
L4248-Series_QSG_TRILINGUAL_R1.indd 7
2021-06-02 7:14:24 PM
2021-06-02 7:14:24 PM
