Lorex L4248 Series - Install the Camera

Install the camera
1. Set the mounting bracket in the desired mounting position.
2. Mark holes through the mounting bracket.
3. Using the included drill bit, drill holes where marked.
4. Using the included screwdriver, secure the bracket with the provided mounting screws.
Optional: If you are mounting the camera into drywall, use the provided drywall anchors.
&DPHUD
Security screw
Mounting bracket
Mounting surface
Screws
Anchors (Optional)
