Lorex Vantage User Manual

CONNECTIVITY
Easy Connect Lorex Auto Port Forward Wizard
Supported Operating Systems 4/8/16 ch: Windows™ XP, Vista, 7
4/8/16 ch: Mac OSX Snow Leopard 10.6 or above
Browsers Internet Explorer & Safari 6.0
Email notification Text with snapshot
Instant Smart Phone Compatibility† Smart Phone & Tablet Compatibility: iPad
®
, iPhone
®
, BlackBerry
(supported model numbers: 9000, 9700, 9800), Android
(version 1.5 & above), Windows Mobile (6.0, 6.5), Symbian
3rd & 5th generation phones.
DDNS Free Lorex DDNS
System Configuration Full setup configuration over network
Ports Programmable by User
Network Protocol TCP/IP / DHCP / UDP / DDNS / PPPoE
Network Interface 10/100-Base-TX, RJ-45
Network Speed Control 48Kb ~ 8MB/sec.
GENERAL
Power Consumption 4/8/16 ch: Approx. 15 watts (HDD Pre-installed)
Supply Voltage 4/8/16 ch: 100VAC-240VAC, 12VDC , 2A, 50/60Hz
Unit Dimensions 4/8/16 ch:11.81”/300mm x 8.66”/220mm x (W x D x H)
1.97”/50mm
Unit Weight (KGs) 4 & 8 ch: 1.32 kgs/2.9 Lbs
16 ch: 1.51s kg/3.33 Lbs
Operating temperature 32° ~ 104° F / 0° ~ 40° C
Humidity 10 ~ 90% NC
DVR:
PRODUCT SPECIFICATIONS
SYSTEM
Operating System Linux (embedded)
Pentaplex Simultaneous View, Record, Playback, Backup & Remote Monitoring
Number of Channels 4/8/16 Channel
Inputs/Outputs
Video IN 4/8/16 x 1Vp-p, CVBS, 75ohms, BNC
Video OUT 4/8 ch: 2 x BNC, 16 ch: 1 x BNC
VGA OUT 4/8/16 ch: Yes
Audio IN 4/8 ch: 1 Line in(RCA), G.711
16 ch: 2 Line in(RCA), G.711
Audio OUT 4/8/16 ch: 1 line out(RCA), G.711
USB Port 1 at the back for Mouse, 1 at the front for firmware upgrade &
USB backup
Video Output Resolution 800x600, 1024x768, 1280x1024
PTZ control RS-485 Pelco D & P Protocol
Display
Live Display 4 ch: 1,4
8 ch: 1, 4, 8
16 ch: 1, 4, 9, 16
Live Display Speed 120 (4 ch)/ 240 (8 ch)/ 480 (16 ch) NTSC
100 (4 ch)/ 200 (8 ch)/ 400 (16 ch) PAL
OSD ON/OFF
System Navigation USB Mouse, IR Remote Controller
Motion Area Setting Adjustable grid (10 x15) NTSC
Adjustable grid (12 x15) PAL
Sensitivity levels 8
Firmware Upgrade Via USB device and Network
User Authority By user group
Time Synchronization Auto time sync by NTP server
RECORDING
Video Compression H.264
Audio Compression G.711
Recording Resolution 4/8 ch: NTSC: 360x240 (CIF), 720x240 (HD1), 720x480 (D1)
4/8 ch: PAL: 360x288 (CIF), 720x288 (HD1), 720x576 (D1)
16 ch: NTSC: 360x240 (CIF), PAL: 360X288 (CIF)
Recording Speed: 4 ch: 120/100 (NTSC/PAL) @ CIF, HD1, 60/50 (NTSC/PAL) @ D1
8 ch: 240/200 (NTSC/PAL) @ CIF, 120/100(NTSC/PAL) @ HDI,
60/50 (NTSC/PAL) @ D1
16 ch: 480/400 (NTSC/PAL) @ CIF
Recording Resolution Setting Per camera for different resolutions (CIF/2CIF/D1). 16 ch: CIF only
Recording Quality Control 3 levels
Recording Schedule By hour, by day, by recording mode, by motion, by channel
Pre Recording Max. 10 Secs
Post Recording Max. 5 Minutes
Reliability Watch-Dog, Auto-recovery after power failure
Covert Video Yes
PLAYBACK
Playback Channel 1~4 Adjustable(4 ch), 1~8 Adjustable (8 ch), 1~16
Adjustable (16 ch)
Playback Speed Variable Max 16x
Playback Players Backup Player
Search By time & event
Log Search Up to 10,00,000 lines for motion detected, configuration
changes, connects/disconnects and video loss.
Audio Play Yes
STORAGE & ARCHIVE
Storage 4/8/16 ch: Up to 1 HDD’s (SATA)
Maximum Capacity 4/8/16 ch: Up to 2TB
Backup Media USB Flash Drive & HDD
Backup File Format H.264 file (AVI generator included)
WIRELESS (LW2232PK4B):
LH010W ECO BLACKBOX Series
CAMERA
RECEIVER
Image Sensor Type 1/4” Color CMOS Image Sensor
Effective Pixels H: 640 V: 480
Image Compression MPEG4
Image Resolution VGA (640x480)
Lens 3.6mm F2.0
Field of View (Diagonal) 55°
AGC On
Power Requirement 9V DC +/- 5%
Power Consumption 430mA Max with IR LED
220mA Max without IR LED
Environment Rating IP66
IR LED Quantity / Type 24 pieces / 850nm
Night Vision Range2 90ft (27m) / 135ft (41m)
Built in Auto IR Turn On / Off CdS Drive Auto IR LED turn On/Off Circuit
Dimensions (W x D x H) 79 x 203 x 117mm / 3.1 x 8.0 x 4.6”
(with antenna and sunshade)
Weight 0.3kg / 0.6lbs
RX Sensitivity -81dBm
Demodulation GFSK
Data Rate 4 Mb/s
Supported Resolution VGA (640x480) up to
25 frames per second
Termination 2x BNC video
Power Requirement 9V DC +/- 5%
Power Consumption 270mA Max
Operating Temperature 14°F ~ 122°F / -10°C ~ 40°C
Range
Dimensions (W x D x H): 53 x 137 x 86mm / 2.1 x 5.4 x 3.4”
(with antenna attached)
Weight: 0.1kg / 0.3lbs
TX Frequency Range 2.400GHz~2.480GHz
TX Power 16dBm
Unobstructed Effective Range 165ft (50m) indoor, 500ft (152m) outdoor
Data Rate 4 Mb/s
Modulation GFSK
Spread Spectrum FHSS
Operating Temperature Range 14°F ~ 122°F / -10°C ~ 40°C
GENERAL

Lorex Vantage Specifications

General

Brand	Lorex
Model	Vantage
Category	Security System
Language	English
