2
|
HOOK2 series | Quick Guide - EN
Micro SD card
The card reader position
depends on model.
System controls dialog
• Option ON
• Option OFF
Display illumination
• Set brightness and select day/night mode from the System Controls dialog
• Repeat short presses on the Power key to cycle the backlight brightness
The Home page
1 2
3
1. Tools panel
2. Page icons
3. Customize option
¼ Note: Page icons on the Home page vary with model type.
Pages
Select a page icon on the Home page to display a page.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lowrance HOOK2 7x GPS TS and is the answer not in the manual?

Lowrance HOOK2 7x GPS TS Specifications

General IconGeneral
Display Size7 inches
Resolution800 x 480 pixels
GPSYes
Waypoints3000
Waterproof RatingIPX7
Split Screen ViewingYes
SonarBroadband Sonar
Power Output200W RMS
Depth Capability500 ft
Display TypeColor TFT
Mounting TypeBracket
Operating Temperature-15°C to +55°C
Storage Temperature-20°C to +60°C
Sonar Frequency200kHz (High CHIRP), 455/800kHz (DownScan)
