6
X-15
MT
Sonar Connector
“Y” Adapter Cable
(Packed with Speed/Temp Sensor)
Temperature Sensor
Speed/Temp Sensor
X-15
MT
Sonar Connector
Temperature and Speed/Temperature Installation Examples
To
Transducer
To
Transducer
To
Additional
Temp. or
Speed
Sensors
(if needed)
To
Additional
Temp.
Sensors
(if needed)
