iS7 Ethernet Option Manual
8
8.
Ethernet Option and Related Keypad Parameters
The functions below are the inverter parameters which shows the
information related with the Modbus TCP and Ethernet IP. In the parameter
column, the “M” stands for the parameters used for Modbus TCP, and “E”
stands for the parameters used for Ethernet IP.
Related keypad parameter with iS7 Ethernet
Option-1 Type - -
Indicates name of the
communication card installed in
the inverter (Ethernet).
M/E
COM-06
FBus S/W Ver - -
Indicates version of the
communication card installed in
the inverter.
M/E
COM-09
FBus Led - -
Shows the ON/OFF data of the
LED on the Ethernet
communication card.
M/E
COM-10
Sets up the IP Address.
M/E
COM-11
Sets up the Subnet Mask.
M/E
COM-13
Sets up the Gateway Address.
M/E
COM-15
Opt Parameter7 0
0~2
Sets up the Ethernet
communication rate.
M/E
COM-17
0
0~11
CIP Input Instance
E
COM-18
0
0~11
CIP Output Instance
E
COM-30
ParaStatus Num 3
0~8
Automatically set up according to
the CIP Input Instance.
E
COM-31
Sets up the inverter data address
which will be read by the client.
E
COM-32
Sets up the inverter data address
which will be read by the client.
E
