Compact & Powerful Inverter iG5A
23
Function group 2
H6
H7
H8
H10
H11
H12
H13
H14
H15
H16
H17
H18
H19
H20
H21
H22
H23
H24
H25
H26
H27
H30
H31
Reset fault history
Dwell frequency
Dwell time
Skip frequency select
Skip frequency low limit 1
Skip frequency high limit 1
Skip frequency low limit 2
Skip frequency high limit 2
Skip frequency low limit 3
Skip frequency high limit 3
S-Curve accel/decel start side
S-Curve accel/decel end side
Input/output phase loss
protection select
Power On Start select
Restart after fault reset selection
Speed search select
Current level during speed search
P gain during speed search
I gain during speed search
Number of auto restart try
Auto restart time
Motor type select
Number of motor poles
0 (No), 1 (Yes)
0~400Hz
0~10sec
0 (No), 1 (Yes)
0~400Hz
0~400Hz
0~400Hz
0~400Hz
0~400Hz
0~400Hz
1~100%
1~100%
0 (Disabled), 1 (Output phase protection),
2 (Input phase protection, 3 (Input/output phase protection)
0 (NO), 1 (YES)
0 (NO), 1 (YES)
0: Speed search disabled
1: Normal accel
2: Operation after fault
3: Normal accel, Operation after fault
4: Restart after instant power failure
5: Normal accel, Restart after instant power failure
6: Operation after fault, Restart after instant power failure
7: Normal accel, Operation after fault,
Restart after instant power failure
8: Power On start
9: Normal accel, Power On start
10: Operation after fault, Power On start
11: Normal accel, Operation after fault, Power On start
12: Restart after instant power failure, Power On start
13: Normal accel, Restart after instant power failure,
Power On start
14: Operation after fault, Restart after instant power failure,
Power On start
15: Normal accel, Operation after fault,
Restart after instant power failure, Power On start
80~200%
0~9999
0~9999
0~10
0~60sec
0.2~7.5kW
2~12
Yes
No
No
No
No
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
1) Only displayed when H10 is set to 1. # H17, H18 are used when F2, F3 are set to 1 (S-curve).
2) Normal acceleration has first priority. Even though #4 is selected along with other bits, Inverter performs Speed search #4.
3) H30 is preset based on Inverter rating.
1)
2)
LED Parameter
Description
Factory Adj. during
display name default run
0 (NO)
5.00
0.0
0 (NO)
10Hz
15Hz
20Hz
25Hz
30Hz
35Hz
40%
40%
0
0 (NO)
0 (NO)
0
100
100
1000
0
1sec
7.5
4
3)
