Compact & Powerful Inverter iG5A
27
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
I51
I52
I53
I54
I55
I56
I57
I59
I60
I61
I62
I63
I64
Analog output level adjustment
Frequency detection level
Frequency detection bandwidth
Multi-function output terminal select
Fault relay select
Fault relay output
Output terminal select when
communication error occurs
Communication protocol select
Inverter number
Baud rate
Drive mode select after loss
of frequency command
Wait time after loss of
frequency command
Communication time setting
100
30.00
10.00
12
17
2
0
0
1
3
0
1.0
5
Input/output group
LED Parameter
Description
Factory Adj. during
display name default run
10~200%
0~400Hz
0: FDT-1
1: FDT-2
2: FDT-3
3: FDT-4
4: FDT-5
5: Overload (OL)
6: Inverter overload (IOL)
7: Motor stall (STALL)
8: Over voltage trip (OV)
9: Low voltage trip (LV)
10: Inverter overheat (OH)
11: Command loss
12: During run
13: During stop
14: During constant run
15: During speed searching
16: Wait time for run signal input
17: Fault relay select
18: Warning for cooling fan trip
0: -
1: When the low voltage trip occurs
2: When the trip other than low voltage trip occurs
3: When the low voltage trip occurs, When the trip other than
low voltage trip occurs
4: When setting the H26 (Number of auto restart try)
5: When the low voltage trip occurs, When setting the H26
(Number of auto restart try)
6: When the trip other than low voltage trip occurs, When setting
the H26 (Number of auto restart try)
7: When the low voltage trip occurs, When the trip other than
low voltage trip occurs, When setting the H26 (Number of
auto restart try)
0: -
1: Multi-function output terminal
2: Multi-function relay
3: Multi-function output terminal, Multi-function relay
0 (Modbus RTU), 1 (LS BUS)
1~32
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
0: Continuous operation at the frequency before its command is lost.
1: Free run stop (Coast to stop)
2: Decel to stop
0.1~12sec
2~100msec
