PARTS
OM 0472SB-A
[27]
SNOWBLOWER ASSEMBLY (BACK)
R
EF. DESCRIPTION QTY PART #
1 Female hitch 1
666807
2 Reduction box 1
4500146
3 Reduction box support 1
669769
4 Reduction box support bracket 2
669768
5 Driveline guard 1
665446
6 Driveline support bracket 1
661406
7 Driveline support 1
665446
8 Hose clamp 1
666583
9
Triangular flange 3 holes 2 657893
10
Bearing with locking collar 1 1/4" hole 1 4300009
11 Female part of driveline 1
659830
12 Carriage bolt 3/8NC X 1 1/4" gr.5, PTD 8
0300009
13 Flat washer 3/8" (7/16" hole) PTD 8
1400004
14 Lockwasher 3/8" PTD 11
1200004
15 Nylon insert locknut 3/8"NC PTD 1
1000006
16 Carriage bolt 3/8NC X 1" gr.5, PTD 3
0300008
17 Nut hex. 3/8"NC, PTD 11
0900003
18 Bolt hex. M10 x 1,5 x 20mm gr.8.8 PTD 3
0200012
19 Lockwasher 10mm PTD 3
1200018
20 Bolt hex. M10 x 1,5 x 16mm gr.8.8 PTD 2
0200011
21 Lockwasher 7/16" PTD 2
1200005
22 Bolt hex. 3/8"NC x 1" gr.5 PTD 1
0100038
23 Bolt hex. M12 x 1,75 x 20mm gr.8.8 PTD 2
0200084
24 Lockwasher 12mm PTD 2
1200019
25 Bolt hex. 5/8"NC x 1 1/4" gr.5 PTD 4
0100092
26 Lockwasher 5/8" PTD 4
1200007
27 Nut hex. 5/8"NC, PTD 4
0900007
28 Bolt hex. 1/4"NC x 2 1/2" gr.5 PTD 1
0100012
29 Nylon insert locknut 1/4"NC PTD 1
1000003
30 Key 1/4" x 1/4" x 1 1/4" 1
654643
31 Setscrew 3/8"NC x 3/8" 1
0500017
32 Hairpin 3mm X 65mm lg 1
1800004
