PARTS
OM 0472SB-A
[31]
WORM GEARBOX ASSEMBLY - IDENTIFIED "4500137S"
REF. DESCRIPTION QTY CODE
Gearbox assembly 1 BER4500137
1 Input shaft 1
BER4500185
2 Bearing 1 1/4" int 1 BER4500151
3 Bearing 25mm int 1 BER4500189
4 Bearing 45mm int 2 BER4500152
5 Oil seal 2" X 1.25" X 0.312 1 BER4500188
6 Oil seal 45 x 60 x 7 2 BER4500153
7 Snap ring 1 BER655087
8 Spacer 25.5 x 38 x 8.35 2 BER4500186
9 Bolt hex 8mm x 1.25 x 16 3 BER0200005
10 Bolt hex 10mm x 1.5 x 20 4 BER0200012
11 Plug 1/4NPT 4 BER663570
12 Pressure plug 1/8"-27 NPT, vent 1 BER654927
13 Key 1/4" x 1/4" x 54.5mm lg 1 BER4500157
14 Key 1/4" x 1/4" x1 1/4" lg 1 BER654643
15 Key 12mm x 8mm x 30mm lg 1 BER4500156
- Shim kit - for output shaft (not shown) 1 BER4500158
- Shim kit - for input shaft (not shown) 1 BER4500187
FIG: RAD1707015
