4 -24
Module : DP 16/32
Number of Teeth : 15T
(1.77 in.)
(0.94 in.)
(0.84 in.)
(0.98 in.)
MID PTO 1 speed gear (15T)
PTO / Engine speed 2000 / 2545 rpm
Rotation direction Counter clockwise (When looking at PTO shaft end)
Shaft dimension
(Unit : inch)
- Spline Teeth: 15T (Where fitted)
③ Specification and dimension of middle PTO shaft
