5 -54
(5) Tail/brake light bulb and turn signal light bulb- Replace
3
2
1
①
Tail/brake light bulb and rear turn
signal light bulb replacement
1. Remove the two screws
①
retaining the taillight
lens and remove the lens.
2. Push in on the tail/brake light bulb
②
or turn
signal light bulb
③
and rotate counter-clockwise
in the socket to remove the old bulb.
3. Insert the new bulb into the socket and turn the
bulb in a clockwise direction until tightened.
4. Install lenses and retaining screws.
NOTE: For about bulb specification, refer to the
chapter 5-6-(4) in this manual.
