2 -1

2. Instruction for Safe Operation

(1) The name of each part

① Roll-Bar type

Hood

(Bonnet)

Steering wheel

Driver’s seat

Fuel tank

Headlights

Tire

Sub step

Front weight

(optional)

Instrument panel

Fender

Bumper

(optional)

ROPS

(Roll bar)
