4 -7
▶When starting power-shuttle model normally, use the power-shuttle lever without
depressing clutch pedal.
Notice
Position control
lever
1. Lift up all the implements
(front/middle/rear) from the ground
after starting engine.
Main gear shift lever
Throttle pedal
Clutch pedal
Throttle lever
Power-shuttle lever
4. Place all the transmission gear
levers (Main, Range, Shuttle lever)
on a suitable position.
5. After pressing down the brake
pedals and release the parking
brake lever.
2. Place the throttle lever to the low
speed position.
3. Place the power-shuttle lever in
neutral position.
6. Place the power-shuttle lever to
the forward or reverse position, and
press down the throttle pedal
slowly when the vehicle begins to
start.
② Power-shuttle model
To Next Page
