14
Lower menu Displayed contents
Voltage
It displays the values of three phase voltage.
If wiring is 3P3W, it can’t display phase
voltage.
Current/freq
It displays the values of current and frequency
of each phase.
M TYPE can display the load factor with %.
Phase It displays the values of all phases.
Power
It displays the values of
ACTIVE,REACTIVE,REV-ACTIVE power.
Energy It displays the values of electric power
Power factor/DFR Power factor, displacement power factor
Harmonics/spectrum
It displays the 2~13th harmonic distortions and
total harmonic distortion with diagram.
Vector diagram
It displays three phase current, voltage with
vector diagram.
If user want to set the relay elements to assign LED, should move cursor to wanted
LED and put the left/right key. If you set the 27R relay elements to first trip assign
LED. You can see the display like above picture.
MEASURMENT
This menu has lower, detail menu like PROTECTIVE RELAY menu.
It displays measurement data on the 8 menu as follows.
