5
1
11
1-
--
- 1
1 1
1 The disp lay window of
The disp lay window of The disp lay window of
The disp lay window of GIPAM
GIPAMGIPAM
GIPAM-
--
-2000
2000 2000
2000
1
11
1.
. .
. MMI
MMIMMI
MMI
1-1-1. LCD
GIPAM-2000 has a 320 x 240 FSTN LCD to display various measurement data, event, and faults
for the user’s convenience. It supports ASCII english text & numbering code and also 20 special
characters. The used fonts are 8 x 12(windows system) and 11 x 18(windows terminal). The
various measurement data, event, and faults are displayed by text and picture on LCD. The
number is decimal system. LCD backlight support users to see the display in dark space. And
the backlight will be turned off by no using for 15 minutes.
LCD display
LCD displayLCD display
LCD display
MENU
MENUMENU
MENU NAME
NAME NAME
NAME
Additional
Additional Additional
Additional Explanation
ExplanationExplanation
Explanation
1-1-2. LCD display components
As above picture, menu name and additional explanation can be located on above and
bellow in case of need.
1-1-3. LED
The LED can be divided into trip assign LED, status LED and expert skill LED.
