① Trip assign LED - It is with yellow and installed by user.( User can set that LED indicates
what user wants. ) GIPAM-2000 type has 6 LEDs. The LED which corresponds to detected
faults is ON when GIPAM-2000 is tripped due to systematic faults. The LED for protection
relay can be cancelled only by RESET KEY like the PICK-UP/TRIP LED.
② Status LED – GIPAM2000 has 4 status LED.
Power supply LED is with green and indicates the status of power supply of GIPAM-2200.
For normal operation it is kept with green light ON but for the abnormal operation it is
blinking every second.
Communication LED is with orange and indicates the status of remote communication. The
LED is blinking while transmitting or receiving data under normal correspondence of
communication card.
Diagnosis/Error LED is with yellow but it is blinking if problem has found with hardware or
program while it is being under self-diagnosis. Under normal operation it is in OFF. Please
contact the official A/S centre in case of blinking of LED.
PICK-UP/TRIP LED is with red and indicates the protection relay of GIPAM-2200. It is
blinking
every second if protection relay is in the condition of Pick-up by systematic faults. It is kept
with red light ON if it is tripped by the operation of protection relay. This LED can be
cancelled only by RESET KEY of protection relay or reset of it with remote communication.
③ Expert skill LED
REMOTE/LOCAL LED is on the upper side of R/L KEY with green & red and indicates the
present control status of GIPAM-2200. It is with GREEN light ON under REMOTE control
and with RED light ON under LOCAL control. These two LEDs shall not be ON or OFF at
the same time.
CB CLOSE/OPEN LED is on the upper side of CLOSE/OPEN KEY with green & red and
indicates
the present status of circuit breaker which is connected to GIPAM
