LSIS GIPAM 2000 - Page 7

7
LED operation Setting
ON Relay trip
Trip assign
OFF OFF in usual
F4 key on relay
setting menu
ON Power on
Power/run
OFF Power off
Comm. flickering
It flickers on
communicating
ON Error detection
Diag/err
OFF
Put the F5 key after clear
the reason of error.
(error reset)
ON Relay trip
flickering The occurrence of relay trip
Trip/pick-up
OFF
OFF in usual.
Put the F5 key after clear
the fault.(reset)
GREEN
Remote mode R/L
(remote/local)
RED Local mode
ON CB1 is ON
CB1 ON
OFF CB1 is OFF
ON CB1 is OFF
CB1 OFF
OFF CB1 is ON
None(default)
ON CB2 is ON
CB2 ON
OFF CB2 is OFF
ON CB2 is OFF
CB2 OFF
OFF CB2 is ON
It doesn’t operate
in case that CB2
is set up to PO.
1-1-4. LED setting and operation.
