LSIS GIPAM 2000 - Page 57

57
PHASE TIME OVER VOLTAGE HIGH STAGE OPERATE (PULSE) 59PH – OP
IX0.1.30
(Addr3.6)
GROUND INSTANTANEOUS OVER VOLTAGE START (PULSE) 64 – IP
IX0.1.31
(Addr3.7)
GROUND INSTANTANEOUS OVER VOLTAGE OPERATE (PULSE) 64 – IOP
IX0.1.32
(Addr4.0)
GROUND TIME OVER VOLTAGE LOW STAGE START (PULSE) 64L – TP
IX0.1.33
(Addr4.1)
GROUND TIME OVER VOLTAGE LOW STAGE OPERATE
(PULSE)
64L – TOP
IX0.1.34
(Addr4.2)
GROUND TIME OVER VOLTAGE HIGH STAGE START (PULSE) 64H – TP
IX0.1.35
(Addr4.3)
GROUND TIME OVER VOLTAGE HIGH STAGE OPERATE
(PULSE)
64H – TOP
IX0.1.36
(Addr4.4)
INSTANTANEOUS NEGATIVE SEQUENCE OVER CURRENT
START (PULSE)
46 – IP
IX0.1.37
(Addr4.5)
INSTANTANEOUS NEGATIVE SEQUENCE OVER CURRENT
OPERATE (PULSE)
46 – IOP
IX0.1.38
(Addr4.6)
TIME NEGATIVE SEQUENCE OVER CURRENT START (PULSE) 46 – TP
IX0.1.39
(Addr4.7)
TIME NEGATIVE SEQUENCE OVER CURRENT OPERATE
(PULSE)
46 – TOP
IX0.1.40
(Addr5.0)
SENSITIVE D.G.R START (PULSE) 67G – P
IX0.1.41
(Addr5.1)
SENSITIVE D.G.R OPERATE (PULSE) 67G – OP
IX0.1.42
(Addr5.2)
TRS Result for CB1(1 for BAD) (Cond. PULSE) TRS1
IX0.1.43
(Addr5.3)
TRS Result for CB2(1 for BAD) (Cond. PULSE) TRS2
IX0.1.44
(Addr5.4)
THERMAL RELAY START (PULSE) 49 – P
IX0.1.45
(Addr5.5)
THERMAL RELAY OPERATE (PULSE) 49 – OP
IX0.1.46
(Addr5.6)
MOTOR STALL RELAY START (PULSE) 48 – P
IX0.1.47
(Addr5.7)
MOTOR STALL RELAY OPERATE (PULSE) 48 – OP
IX0.1.48
(Addr6.0)
LOCKED ROTOR START (PULSE) 51LR – P
IX0.1.49
(Addr6.1)
LOCKED ROTOR OPERATE (PULSE) 51LR – OP
IX0.1.50
(Addr6.2)
DIRECTIONAL GROUND START (PULSE) 67N – P
IX0.1.51
(Addr6.3)
DIRECTIONAL GROUND OPREATE (PULSE) 67N – OP
IX0.1.52
(Addr6.4)
RECLOSING PREPARED (PULSE) 79 – PR
IX0.1.53
(Addr6.5)
RECLOSING DEAD TIMER #1 COUNTING (PULSE) 79 – DT1
IX0.1.54
(Addr6.6)
RECLOSING DEAD TIMER #2 COUNTING (PULSE) 79 – DT2
IX0.1.55
(Addr6.7)
RECLOSING DEAD TIMER #3 COUNTING (PULSE) 79 – DT3
IX0.1.56
(Addr7.0)
RECLOSING DEAD TIMER #4 COUNTING (PULSE) 79 – DT4
IX0.1.57
(Addr7.1)
RECLOSING DEAD TIMER #5 COUNTING (PULSE) 79 – DT5
IX0.1.58
(Addr7.2)
RECLOSING PROCESS (PULSE) 79-PC
IX0.1.59
(Addr7.3)
RECLOSING SHOT #1 (PULSE) 79 – S1
IX0.1.60
(Addr7.4)
RECLOSING SHOT #2 (PULSE) 79 – S2
IX0.1.61
(Addr7.5)
