LSIS GIPAM 2000 - Page 58

58
RECLOSING SHOT #3 (PULSE) 79 – S3
IX0.1.62
(Addr7.6)
RECLOSING SHOT #4 (PULSE) 79 – S4
IX0.1.63
(Addr7.7)
RECLOSING SHOT #5 (PULSE) 79 – S5
IX0.2.0
(Addr8.0)
RECLOSING SUCCESS (LATCH) 79 – SC
IX0.2.1
(Addr8.1)
RECLOSING FAIL/LOCK-OUT (LATCH) 79 – FL
IX0.2.2
(Addr8.2)
CB1 ON SW (PULSE)
IX0.2.3
(Addr8.3)
CB1 OFF SW (PULSE)
IX0.2.4
(Addr8.4)
CB2 ON SW (PULSE)
IX0.2.5
(Addr8.5)
CB2 OFF SW (PULSE)
IX0.2.6
(Addr8.6)
CB1 RECLOSE (PULSE)
IX0.2.7
(Addr8.7)
Control Contact 1 (PULSE/LATCH)
IX0.2.8
(Addr9.0)
Control Contact 2 (PULSE/LATCH)
IX0.2.9
(Addr9.1)
Control Contact 3 (PULSE/LATCH)
IX0.2.10
(Addr9.2)
Control Contact 4 (PULSE/LATCH)
IX0.2.11
(Addr9.3)
Control Contact 5 (PULSE/LATCH)
IX0.2.12
(Addr9.4)
Control Contact 6 (PULSE/LATCH)
IX0.2.13
(Addr9.5)
Control Contact 7 (PULSE/LATCH)
IX0.2.14
(Addr9.6)
Control Contact 8 (PULSE/LATCH)
IX0.2.15
(Addr9.7)
Remote / Local (LATCH)
IX0.2.16
(Addr10.0)
Alarm Reset(F5) (PULSE)
IX0.2.17
(Addr10.1)
Power Fail(Cond. PULSE)
IX0.2.18
(Addr10.2)
DIAG-ERROR(produced after 2004.05)
IX0.2.19
(Addr10.3)
CB1 Trip Relay Test(PULSE) TRIP_TEST1
IX0.2.20
(Addr10.4)
CB2 Trip Relay Test(PULSE) TRIP_TEST2
IX0.2.21
(Addr10.5)
RECLOSING CANCEL(LATCH) 79 - CC
IX0.2.22
(Addr10.6)
OVER WATT DEMAND ALARM
(produced after 2004.05)
IX0.2.24
OVER VAR DEMAND ALARM
(
produced
after 2004.05)
IX0.2.25
OVER 3P I DEMAND ALARM
(produced after 2004.05)
IX0.2.26
RATIO DIFFERENTIAL RELAY LOW STAGE START(PULSE) 87L - P
IX0.2.32
(Addr12.0)
RATIO DIFFERENTIAL RELAY LOW STAGE OPERATE (PULSE) 87L - OP
IX0.2.33
(Addr12.1)
RATIO DIFFERENTIAL RELAY HIGH STAGE START (PULSE) 87H - P
IX0.2.34
(Addr12.2)
RATIO DIFFERENTIAL RELAY HIGH STAGE OPERAGE (PULSE) 87H - OP
IX0.2.35
(Addr12.3)
PHASE INSTANTANEOUS OVER CURRENT2 LOW STAGE
START (PULSE)
250PL – P
IX0.2.40
(Addr13.0)
