PHASE INSTANTANEOUS OVER CURRENT2 LOW STAGE
OPERATE (PULSE)
250PL - OP
IX0.2.41
(Addr13.1)
PHASE INSTANTANEOUS OVER CURRENT2 HIGH STAGE
START (PULSE)
250PH – P
IX0.2.42
(Addr13.2)
PHASE INSTANTANEOUS OVER CURRENT2 HIGH STAGE
OPERATE (PULSE)
250PH – OP
IX0.2.43
(Addr13.3)
PHASE TIME OVER CURRENT2 LOW STAGE START (PULSE) 251PL - P
IX0.2.44
(Addr13.4)
PHASE TIME OVER CURRENT2 LOW STAGE OPERAGE (PULSE) 251PL - OP
IX0.2.45
(Addr13.5)
PHASE TIME OVER CURRENT2 HIGH STAGE START (PULSE) 251PH - P
IX0.2.46
(Addr13.6)
PHASE TIME OVER CURRENT2 HIGH STAGE OPERATE (PULSE) 251PH - OP
IX0.2.47
(Addr13.7)
PHASE INSTANTANEOUS OVER CURRENT3 LOW STAGE
START (PULSE)
350PL - P
IX0.2.48
(Addr14.0)
PHASE INSTANTANEOUS OVER CURRENT3 LOW STAGE
OPERATE (PULSE)
350PL - OP
IX0.2.49
(Addr14.1)
PHASE INSTANTANEOUS OVER CURRENT3 HIGH STAGE
START (PULSE)
350PH – P
IX0.2.50
(Addr14.2)
PHASE INSTANTANEOUS OVER CURRENT3 HIGH STAGE
OPERATE (PULSE)
350PH - OP
IX0.2.51
(Addr14.3)
PHASE TIME OVER CURRENT3 LOW STAGE START (PULSE) 351PL – P
IX0.2.52
(Addr14.4)
PHASE TIME OVER CURRENT3 LOW STAGE OPERATE (PULSE) 351PL - OP
IX0.2.53
(Addr14.5)
PHASE TIME OVER CURRENT3 HIGH STAGE START (PULSE) 351PH – P
IX0.2.54
(Addr14.6)
PHASE TIME OVER CURRENT3 HIGH STAGE OPERATE (PULSE) 351PH - OP
IX0.2.55
(Addr14.7)
GROUND INSTANTANEOUS OVER CURRENT2 LOW STAGE
START (PULSE)
250NL - P
IX0.2.56
(Addr15.0)
GROUND INSTANTANEOUS OVER CURRENT2 LOW STAGE
OPERATE (PULSE)
250NL - OP
IX0.2.57
(Addr15.1)
GROUND INSTANTANEOUS OVER CURRENT2 HIGH STAGE
START (PULSE)
250NH - P
IX0.2.58
(Addr15.2)
GROUND INSTANTANEOUS OVER CURRENT2 HIGH STAGE
OPERATE (PULSE)
250NH - OP
IX0.2.59
(Addr15.3)
GROUND TIME OVER CURRENT2 LOW STAGE START (PULSE) 251NL - P
IX0.2.60
(Addr15.4)
GROUND TIME OVER CURRENT2 LOW STAGE OPERATE
(PULSE)
251NL - OP
IX0.2.61
(Addr15.5)
GROUND TIME OVER CURRENT2 HIGH STAGE START (PULSE) 251NH - P
IX0.2.62
(Addr15.6)
GROUND TIME OVER CURRENT2 HIGH STAGE OPERATE
(PULSE)
251NH - OP
IX0.2.63
(Addr15.7)
