S100/H100 Conduit Option Installation Manual
② Fasten the Conduit Option to fit on the side of ground terminals of the product using the prescribed bolt as
shown in the Figure 5.
Figure 5. Install
③ Install the Power cover again.
Figure 6. After installation
8
