z Conduit Kit
Conduit Kit Model
Inverter Conduit Kit 1 SV004IG5A-2/4, SV008IG5A-2/4, SV004IG5A-1
Inverter Conduit Kit 2 SV015IG5A-2/4, SV008IG5A-1
Inverter Conduit Kit 3
SV022IG5A-2/4, SV037IG5A-2/4, SV040IG5A-2/4,
SV015IG5A-1
Inverter Conduit Kit 4 SV055IG5A-2/4, SV075IG5A-2/4
Inverter Conduit Kit 5 SV110IG5A-2/4, SV150IG5A-2/4
Inverter Conduit Kit 6 SV185IG5A-2/4, SV220IG5A-2/4
13.5 EMC filter
(Reserved)
13.6 Braking resistor
100 % braking 150% braking
Input
Voltage
Inverter capacity
[kW]
[Ω]
[W]*
[Ω]
[W]*
0.4 400 50 300 100
0.75 200 100 150 150
1.5 100 200 60 300
2.2 60 300 50 400
3.7 40 500 33 600
5.5 30 700 20 800
7.5 20 1000 15 1200
11.0 15 1400 10 2400
15.0 11 2000 8 2400
18.5 9 2400 5 3600
200V
22.0 8 2800 5 3600
0.4 1800 50 1200 100
0.75 900 100 600 150
1.5 450 200 300 300
2.2 300 300 200 400
3.7 200 500 130 600
5.5 120 700 85 1000
7.5 90 1000 60 1200
11.0 60 1400 40 2000
15.0 45 2000 30 2400
18.5 35 2400 20 3600
400V
22.0 30 2800 10 3600
* The wattage is based on Enable duty (%ED) 5% with continuous braking time 15 sec.
