Appendix 1 Flag List
App. 1-1
(2) “E” type
Word
Bit
Variables
Function
Description
F000~1
-
_SYS_STATE
Mode and state
Indicates PLC mode and operation State.
F0000
_RUN
Run
Run state.
F0001
_STOP
Stop
Stop state.
F0002
_ERROR
Error
Error state.
F0003
_DEBUG
N/A
F0004
_LOCAL_CON
Local control
Local control mode.
F0006
_REMOTE_CON
Remote mode
Remote control mode.
F0008
_RUN_EDIT_ST
Editing during RUN
Editing program download during RUN.
F0009
_RUN_EDIT_CHK
Editing during RUN
Internal edit processing during RUN.
F000A
_RUN_EDIT_DONE
Edit done during RUN
Edit is done during RUN.
F000B
_RUN_EDIT_END
Edit end during RUN
Edit is ended during RUN.
F000C
_CMOD_KEY
Operation mode
Operation mode changed by key.
F000D
_CMOD_LPADT
Operation mode
Operation mode changed by local PADT.
F000E
_CMOD_RPADT
Operation mode
Operation mode changed by Remote PADT.
F000F
_CMOD_RLINK
Operation mode
Operation mode changed by Remote
communication module.
F0010
_FORCE_IN
Forced input
Forced input state.
F0011
_FORCE_OUT
Forced output
Forced output state.
F0014
_MON_On
Monitor
Monitor on execution.
F0015
_USTOP_On
Stop
Stop by Stop function.
F0016
_ESTOP_On
EStop
Stop by EStop function.
F0017
_CONPILE_MODE
Compile
Compile on execution.
F0018
_INIT_RUN
Initialize
Initialization task on execution.
F001C
_PB1
Program Code 1
Program Code 1 selected.
F001D
_PB2
Program Code 2
Program Code 2 selected.
F001E
_CB1
Compile Code 1
Compile Code 1 selected.
F001F
_CB2
Compile Code2
Compile Code 2 selected.
F002~3
-
_CNF_ER
System error
Reports heavy error state of system.
F0021
_IO_TYER
Module Type error
Module Type does not match.
F0022
_IO_DEER
Module detachment
error
Module is detached.
F0024
_IO_RWER
Module I/O error
Module I/O error.
F0025
_IP_IFER
Module interface error
Special/communication module interface error.
F0026
_ANNUM_ER
External device error
Detected heavy error in external
Device.
