Appendix 1 Flag List
App. 1-2
Word
Bit
Variable
Function
Description
F002~3
F0028
_BPRM_ER
Basic parameter
Basic parameter error.
F0029
_IOPRM_ER
IO parameter
I/O configuration parameter error.
F002A
_SPPRM_ER
Special module parameter
Special module parameter is
Abnormal.
F002B
_CPPRM_ER
Communication module
parameter
Communication module parameter
is abnormal.
F002C
_PGM_ER
Program error
Program error.
F002D
_CODE_ER
Code error
Program Code error.
F002E
_SWDT_ER
System watchdog
System watchdog operated.
F0030
_WDT_ER
Scan watchdog
Scan watchdog operated.
F004
-
_CNF_WAR
System warning
Reports light error state of system.
F0041
_DBCK_ER
Backup error
Data backup error.
F0043
_ABSD_ER
Operation shutdown error
Stop by abnormal operation.
F0046
_ANNUM_WAR
External device error
Detected light error of external device.
F0048
_HS_WAR1
N/A
F0049
_HS_WAR2
N/A
F0054
_P2P_WAR1
P2P parameter 1
P2P – parameter 1 error.
F0055
_P2P_WAR2
N/A
F0056
_P2P_WAR3
N/A
F005C
_CONSTANT_ER
Constant error
Constant error.
F009
-
_USER_F
User contact
Timer used by user.
F0090
_T20MS
20ms
20ms cycle Clock.
F0091
_T100MS
100ms
100ms cycle Clock.
F0092
_T200MS
200ms
200ms cycle Clock.
F0093
_T1S
1s Clock
1s cycle Clock.
F0094
_T2S
2 s Clock
2s cycle Clock.
F0095
_T10S
10 s Clock
10s cycle Clock.
F0096
_T20S
20 s Clock
20s cycle Clock.
F0097
_T60S
60 s Clock
60s cycle Clock.
F0099
_On
Ordinary time On
Always On state Bit.
F009A
_Off
Ordinary time Off
Always Off state Bit.
F009B
_1On
1scan On
First scan On Bit.
F009C
_1Off
1scan Off
First scan OFF bit.
F009D
_STOG
Reversal
Reversal every scan.
