LTH Electronics MXD70 Series User Manual

Registers
Modbus RS485 Interface
Operating Guide
- 49 -
Registers
Suspended Solids / Turbidity Configuration Continued
4963 Get/Set Channel 1 Curve A Point
3*
FLOAT Curve A Point 3 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5553 Channel 2
6153 Channel 3
4965 Get/Set Channel 1 Curve A Sensor
Point 3*
FLOAT Curve A Sensor Point 3
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5555 Channel 2
6155 Channel 3
4967 Get/Set Channel 1 Curve A Point
4*
FLOAT Curve A Point 4 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5557 Channel 2
6157 Channel 3
4969 Get/Set Channel 1 Curve A Sensor
Point 4*
FLOAT Curve A Sensor Point 4
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5559 Channel 2
6159 Channel 3
4971 Get/Set Channel 1 Curve A Point
5*
FLOAT Curve A Point 5 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5561 Channel 2
6161 Channel 3
4973 Get/Set Channel 1 Curve A Sensor
Point 5*
FLOAT Curve A Sensor Point 5
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5563 Channel 2
6163 Channel 3
4975 Get/Set Channel 1 Curve A Point
6*
FLOAT Curve A Point 6 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5565 Channel 2
6165 Channel 3
4977 Get/Set Channel 1 Curve A Sensor
Point 6*
FLOAT Curve A Sensor Point 6
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5567 Channel 2
6167 Channel 3
4979 Get/Set Channel 1 Curve A Point
7*
FLOAT Curve A Point 7 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5569 Channel 2
6169 Channel 3
4981 Get/Set Channel 1 Curve A Sensor
Point 7*
FLOAT Curve A Sensor Point 7
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5571 Channel 2
6171 Channel 3
4983 Get/Set Channel 1 Curve A Point
8*
FLOAT Curve A Point 8 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5573 Channel 2
6173 Channel 3
4985 Get/Set Channel 1 Curve A Sensor
Point 8*
FLOAT Curve A Sensor Point 8
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5575 Channel 2
6175 Channel 3
