Registers
Modbus RS485 Interface
Operating Guide
- 51 -
Registers
Suspended Solids / Turbidity Configuration Continued
5012 Get/Set Channel 1 Curve B Point
5*
FLOAT Curve B Point 5 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5602 Channel 2
6202 Channel 3
5014 Get/Set Channel 1 Curve B Sensor
Point 5*
FLOAT Curve B Sensor Point 5
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5604 Channel 2
6204 Channel 3
5016 Get/Set Channel 1 Curve B Point
6*
FLOAT Curve B Point 6 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5606 Channel 2
6206 Channel 3
5018 Get/Set Channel 1 Curve B Sensor
Point 6*
FLOAT Curve B Sensor Point 6
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5608 Channel 2
6208 Channel 3
5020 Get/Set Channel 1 Curve B Point
7*
FLOAT Curve B Point 7 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5610 Channel 2
6210 Channel 3
5022 Get/Set Channel 1 Curve B Sensor
Point 7*
FLOAT Curve B Sensor Point 7
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5612 Channel 2
6212 Channel 3
5024 Get/Set Channel 1 Curve B Point
8*
FLOAT Curve B Point 8 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5614 Channel 2
6214 Channel 3
5026 Get/Set Channel 1 Curve B Sensor
Point 8*
FLOAT Curve B Sensor Point 8
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5616 Channel 2
6216 Channel 3
5028 Get/Set Channel 1 Curve B Point
9*
FLOAT Curve B Point 9 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5618 Channel 2
6218 Channel 3
5030 Get/Set Channel 1 Curve B Sensor
Point 9*
FLOAT Curve B Sensor Point 9
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5620 Channel 2
6220 Channel 3
5032 Get/Set Channel 1 Curve B Point
10*
FLOAT Curve B Point 10 Value
*(Not Available when
Units Set to PS)
Value Dependant On
Range
5622 Channel 2
6222 Channel 3
5034 Get/Set Channel 1 Curve B Sensor
Point 10*
FLOAT Curve B Sensor Point 10
Value
*(Not Available when
Units Set to PS)
0 to 16000
0 to 32000 (turbidity)
5624 Channel 2
6224 Channel 3
5036 Get/Set Channel 1 Input Filter INT Suspended Solids Input
Filter
1555 = Filter Out
5626 Channel 2 1556 = 1 Second
6226 Channel 3 1557 = 2 Seconds
1558 = 4 Seconds
1559 = 8 Seconds
1560 = 16 Seconds
1561 = 32 Seconds
