LTS Scale DR2100A - SYSTEM DIAGNOSTICS AND SETUP; DISPLAY MESSAGES

LTSscale.com Page 8 of 28 REV F – 2018.04.09
LTS DR2100A/AN Indicator
DISPLAY MESSAGES
ERROR Messages
DESCRIPTION
SOLUTION
*ERROR*
OUT OF LEVEL
Scale is tipped beyond the
maximum weighing angle.
Tilt mast until forks are level. If off left to
right then move truck to a level position.
1) Bad Load cell cable.
2) Bad Angle sensor.
3) Incorrect Angle settings
OUT OF RANGE
Indicates an overload condition
exists. The weight signal is far
beyond the scale capacity.
If there is weight on the scale it should
be removed immediately.
If no weight is on the scale check for:
1) Bad or damaged Load Cell Cable.
2) Bad internal wiring harness.
Check load cell signal. Consult Factory.
****OVERLOAD****
Indicates an overload condition.
The Gross weight as measured
from the zero value 105% of scale
capacity.
Weight in question should be
immediately removed from the scale.
If the total weight on the scale is known
to be less than capacity then check
scale calibration.
DR21-190B
Displayed on power-up. Indicates
Model and program number.
A number may have been
entered and not cleared.
Bad Power.
If indicator display does not continue
past this display then:
1) Press DEL then ENTER key
2) Check power supply.
3) Turn truck off and power up if OK
check truck ignition wires and
distributor cap.
EXCEEDS CAPACITY
Tried to enter a tare larger than
the Scales Capacity.
Tare value must be less than the
calibrated weighing capacity of the
scale.
INHIBIT
Remote Input 1 or 2 is closed and
Input function has been
configured to prevent all scale
weighing functions.
Consult factory.
ITEM LOCKED OUT
Displayed if functions have been
disabled (LOCKED OUT).
Function will not operate without
enabling function.
LOW BATTERY
Input power to the DR2100AN
has dropped below 11 VDC.
Correct low voltage condition.
Reset indicator by holding DEL and R
keys
