LTS Scale DR2100A - INDICATOR SETUP AND CONFIGURATION CODES

LTSscale.com Page 13 of 28 REV F – 2018.04.09
LTS DR2100A/AN Indicator
INDICATOR SETUP
This section provides setup and calibration instructions for the DR2100 indicator. The indicator
setup and calibration is accomplished by entering various configuration codes through the
keyboard.
Configuration Codes
Note: The indicator must be placed in the program mode prior to entering a configuration code.
See the following list of configuration codes that may be accessed. To enter the program mode,
Key 9080 and The display will indicate [ PRESS CAL SWITCH ], Press CAL switch once. This
switch is located on the main board and can be accessed by removing the rear cover of the
indicator.
Code Listing
Function NTEP
2100
Keyboard Lockout
2104
Expanded Test Mode ( X10 )
2105
Restore Name On Top Line
2169
Load Defaults
6969
Initialize Clock Chip
9080
Setup
9081
Four-Point Calibration
9083
Configure Remote Inputs
9084
Configure Print
9085
Set Time & Date
9086
Raw A/D, Battery Test
9087
Auto Shut Off and Backlight Timer
9088
APW Recall/Store
9089
Program Name Through Serial Port
9090
Single-Point Calibration
9091
View / Store Calibration Factors
9092
View / Set Angle Zero and Span
9093
View / Set Angle Factors
9094
Out-of-Level Calibration
Note: if display shows “LOCKED OUT” use configuration Code 2100 to unlock specific
function or key to enable viewing or changing.
