LTS DR2100A/AN Indicator
Angle Calibration Numbers – DR2100AN only
1.59. Press keys 9092. Press Enter Key.
9092
1.60. Press DEL key.
GROSS = 0
FB=+X.X LR=+X.X
1.61. Press ENTER key.
Note: DO NOT select “YES”. Angle Zero set at the factory.
SET ANGLE ZERO
YES *NO
1.62. Press ENTER key. Record value.
FB ANGLE ZERO
NUMBER =
1.63. Press ENTER key. Record value.
LR ANGLE ZERO
NUMBER =
1.64. Press ENTER key. Record value.
FB ANGLE SPAN
FACTOR =
1.65. Press ENTER key. Record value.
LR ANGLE SPAN
FACTOR =
1.66. Press ENTER key. Record value.
FRONT TO FRONT
*NO YES
1.67. Press 9093 keys. Press ENTER key.
9093
1.68. Record value:
ZONE 1 FACTOR
NUMBER
=1.0000000
1.69. Press ENTER key. Record value.
ZONE 2 FACTOR
NUMBER
=1.0000000
1.70. Press ENTER key. Record value.
ZONE 3 FACTOR
NUMBER
=1.0000000
1.71. Press ENTER key. Record value.
ZONE 4 FCTOR
NUMBER
=1.0000000
1.72. Press ENTER key. Record value.
ZONE 5 FACTOR
NUMBER
=1.0000000
1.73. Press ENTER key. Record value.
ZONE 6 FACTOR
NUMBER
=1.0000000
1.74. Press ENTER key. Record value.
ZONE 7 FACTOR
NUMBER
=1.0000000
1.75. Press ENTER key. Record value.
ZONE 8 FACTOR
NUMBER
=1.0000000
1.76. Press ENTER key. Record value.
ZONE 1 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.77. Press ENTER key. Record value.
ZONE 2 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.78. Press ENTER key. Record value.
ZONE 3 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.79. Press ENTER key. Record value.
ZONE 4 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.80. Press ENTER key. Record value.
ZONE 5 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.81. Press ENTER key. Record value.
ZONE 6 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.82. Press ENTER key. Record value.
ZONE 7 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
1.83. Press ENTER key. Record value.
ZONE 8 ANGLE SP
NUMBER =3.50
CHANGE TO 4.80
