20
placed securely under the square tabs in the routing channel.
4. Snap one end of the coiled handset cord into the Handset jack (5 in the
figure above). This jack is labeled . Thread the cord into the
channel leading to the side edge of the voice terminal (4 in the figure
above).
5. Turn the telephone right side up, with the front facing you.
6. Snap the free end of the handset cord into the handset and place the
handset in the cradle.
7. Snap the free end of the line cord into the modular wall jack.
8. Lift the handset and listen for dial tone. If there is no dial tone, check all
wire connections to make sure they are secure.
Wall Installation
Note: For wall-mounting, you will need a 1-foot line cord. This cord is
not
supplied with the telephone, but can be ordered by using this
comcode: 103786760.)
If you are wall-mounting the telephone, you should remove the
tray from the base of the telephone. For this purpose, use the
instructions listed under “Removing the Telephone Tray” later in this
guide.
1. Make sure the 8-conductor wall mount plate is in place.
2. Do the following to reverse the handset hook. (The handset retainer is
located under the handset as shown in a in Figure 6.)
— In order to release the handset retainer hook, press down on the
hook and slide it toward the top of the telephone. (See b in the figure
below.)
— Rotate the hook 180 degrees (as in c below) and then slide it back
into its slot so the bottom part now sticks out from the top. (See d in
Figure 6 below.) Snap the hook firmly into place.
