22
FIGURE 7 Removing the Desktop Stand
5. Turn the desktop stand so that the larger end is facing down.
6. Reinstall the stand using the tabs and tab slots shown in Figure 7.
7. Snap the line cord into the “LINE” jack in the bottom of the telephone
and coil the excess cord in the back of the deskstand.
8. Snap one end of the coiled handset cord into the Handset jack
(labeled ).
9. Snap the free end of the line cord into the wall jack.
10. Place the base of the telephone on the wall-jack mounting studs,
and pull downward until it is secure. (See Figure 8.)
1
2
