DACS II/Rel 8.2.6 April 2000
2-35
DACS II/Rel 8.2.6
MML
RTRV,STATE,EQPT,NPC,LPBK
53131
TH NPC numbers listed by unit, module, and NPC Number
Unit Type HT (HDS3U)
NOTE:
The valid TH NPC numbers are: 01-03, 05-07, 09-11, 13-15, 17-19, 21-23,
25-27.
PA, PB, and PC type numbers listed by unit, module, and NPC
Number Unit Type FT (IFTU2/IFTU/FTU)
The range of NPCs in the denial messages will be given either
as module or unit boundaries depending upon the reason for the
denial.
1.544 Mbit/s Termination
spp
Loopback Type
Values of "spp" are presented in NPC order, grouped within
messages by Facility Terminating Module (FTM). For FTMs
in Facility Terminating Units, each row of output contains 10
values. For FTMs in DS3 Units, each row of output contains 7
values.
s
Explanation
*
Loopback enabled
’ ’
Loopback disabled (The "s" character is a "space".)
pp Explanation
NP
Near-end payload loopback active (ANSI - DA/TA
type NPCs)
FP
ANSI Far-end payload loopback active
FL
ANSI Far-end line loopback active
NN
No loopback active
Unit Module NPC
01 - 16 1 - 6 01 - 28
Unit Module NPC
01 - 16 1 - 4 01 - 32
