Specifications
Overview
Use only a 120-volt, 208-volt, or 240-volt AC supply, 50/60 hertz wall outlet that has a
dedicated and properly grounded circuit, and is rated for at least 15 ampere.
Whenever possible, use a dedicated receptacle with a single socket. If the receptacle
has two sockets, do not plug any other items into the other socket.
The Mobile Charging Cable is 20 feet (6 meters) long. Use an existing outlet or install a
new outlet within approximately 13 feet (4 meters) of the vehicle’s charge port and at
least 18 inches (45 centimeters) above the ground. The charge port door is located to
the rear of the driver side front wheel.
DANGER: RISK OF FIRE OR EXPLOSION
WARNING: RISK OF ELECTRIC SHOCK
Do not use extension cables, a multi-outlet adaptor, a multi-plug, a conversion plug, or a
power strip. Using these items can cause damage to the equipment and increase the risk
of electric shock or fire.
WARNING: RISK OF ELECTRIC SHOCK
Use the Lucid Mobile Charging Cable only for electric vehicles. Using the Lucid Mobile
Charging Cable for anything other than electric vehicles can damage the equipment and
increase the risk of electric shock.
Specifications Reference
Voltage Maximum Current
100⁄240V AC single-phase 40A max, controlled by adaptor
Grid Frequency
50 Hz / 60 Hz
Mobile Charging Cable Control Box Dimensions and Weight
Height 7.1 in /180 mm
Width 3.5 in /90 mm
Depth 2.0 in /50 mm
Weight 8.2 lbs / 3.7 Kg
Operating Temperature Enclosure Rating
-30° C to +50° C 4x (Waterproof)
Ventilation
Not Required
Overview 8
