Mobile Charging Cable Status Lights
The Mobile Charging Cable Control Box includes lights that indicate device status. Refer
to the following table to understand device status.
WARNING: RISK OF ELECTRIC SHOCK
Do not service and/or open the equipment. Opening the equipment can cause electrical
shock.
Light Colour Light Animation What it Means Troubleshooting Steps
No Light — Power off Check power supply
White Constant Ready to charge/
communicating
—
White Flashing Charging in progress —
Red One flash GFCI fault Unplug and then plug
the charging cable
into a power outlet.
Try a different outlet.
Red Two flashes Relay error Unplug and then plug
the charging cable
into a power outlet.
Red Three flashes Loss of ground Check if correct plug
is used and if plugs
are fully inserted. Try
a different outlet.
Red Four flashes Overtemperature
detected in plug
Check if plugs are
fully inserted. Try
charging in a cooler
area.
Red Five flashes Overtemperature
detected in EVSE
relay
Unplug and then plug
the charging cable
into a power outlet.
Red Six flashes Pilot signal error Unplug and then plug
into power outlet.
Ensure vehicle
software is up to
date.
Red Seven flashes Undervoltage error Unplug and then plug
the charging cable
into a power outlet.
Try a different outlet.
Red Eight flashes Overvoltage error Unplug and then plug
the charging cable
into a power outlet.
Try a different outlet.
