GB Operating manual – multifunction measuring meter XA1000 / XP200 / XP400 • 08_2015 14
"Measuring mode – Flowrate – Automatic measurement" screen
58 Shows the measured flow rate as a numerical value in the
selected unit (e.g. m/s).
You can select the unit under 48 in fig. A., page 13.
59 Shows the measured flow rate as visual bars.
Note!
This display is only available when measuring flow values.
The representations in fig. C. can slightly deviate depending
on the previous setting.
60 Shows the measured temperature value.
61 Shows the remaining time until the automatic measurement
finishes.
62 Opens a screen for selecting the recording duration (see fig.
D.).
63 Starts recording.
The key turns red once recording has started.
Note!
During an active recording it is not possible to switch off the
multifunction measuring meter with the "On/Off" key.
Automatic switch-off is also deactivated. First stop the
recording by pressing key 64 and then turn off the device.
64 Stops the current recording. The detected values are
automatically saved to the current measuring project.
65 Pauses the current recording.
Key 63 flashes.
Press this key again to continue recording.
