Lukas HT 90 - Wiring Diagram; Control of the Operating Movements

10
4.4 Control of the operating movements
Pressureisappliedbyahandpump.
Duetothespringforce,thepistonrodretractsagainassoonaspressurestopsbeingapplied
andthepressurecanbereleasedviathesupplyline(notblockedandnopressureapplied).
4.3 Wiring diagram
Thewiringdiagramisshownhereinsimpliedformtoenablecomprehensionofthefunction.
1 Femalecoupling
2 Cylinder
3 Claw
4 Base
1
2
3
4
JL-8
