Lukas HT 90 - 11 Technical Data

23
11. Technical data
Becauseallvaluesaresubjecttotolerances,theremaybeminordi󰀨erencesbetweenthe
dataforyourdeviceandthedatainthefollowingtables.
* 1MPa=10bar
** Volumeofhydraulicuidrequiredtooperatethedevice
Device type HT 90 HT 99 JL-8
Item number 81-85-21 81-85-31 362R549
Compression
force(inall
operatingranges)
[kN] 95
95 35
[lbf.] 21358 21358 7869
Piston stroke
[mm] 100 100 190
[in.] 3.94 3.94 7.48
Length (retracted)
[mm] 206 206 335
[in.] 8.11 8.11 13.2
Length (extended)
[mm] 306 306 540
[in.] 12.0 12.0 21.2
Dimensions
W x H
[mm] 110x125 280 x 128
[in.] 4.33 x 4.92 11.0 x 5.04
Weight incl.
hydraulic uid
lling
[kg] 5.7 6.0 7.2
[lbs.] 12.6 13.2 15.9
max. operating
pressure
[Mpa] * 70
[psi.] 10000
Operating uid
quantity
[cm
3
] ** 138 131
[gal.-US] 0.04 0.03
Coupling system Screwedcoupling
(Flat-Face)quick-disconnect
coupling
