Lukas HT 90 - Coupling of Screwed Couplings (on HT 90); Coupling of Flat-Face Quick-Disconnect Couplings (on HT 99 and JL-8)

12
Thedeviceisconnectedtothehydraulicpumpwithouttheriskofconnectionerrorbymeans
ofscrewedcouplinghalves(femaleandmalecounterparts).
5.2 Coupling of screwed couplings (on HT 90)
The device is connected to the hand pump without the risk of connection error using
Flat-Facequick-disconnectcouplinghalves(femaleandmale).
NOTE:
Couplingofthedevicesisonlypossiblewhenthehosesaredepressurised.
Removethedustcapsbeforecouplingandthenpushthemaleconnectorintothefemale
connector.Thenscrewthethreadedsleeveofthefemaleconnectorontothemalethreadon
themalecouplingandtightenhand-tight.Theconnectionisnowmade.
Uncouplingisdoneinthereverseorder.
NOTE:
Couplingofthedevicesisonlypossiblewhenthehosesaredepressurised.
Fordustprotection,thesupplieddustcapsmustberetted.
5.3 Coupling of Flat-Face quick-disconnect couplings (on HT 99
and JL-8)
Toconnectthedevice,pushthemaleintothefemalecounterpart.Tolock,turnthesleeveof
themalecounterpartby90°.
Todecouple,turnthesleeveofthemalecounterpartby90°againandthenpullback.
Ahosewitha(Flat-Face)femalequick-disconnectcouplingismountedonthedevice.Itis
coupleddirectlytothehandpump.
5.1.3. Jack Rabbit Tool JL-8
