4.3 Wiring diagram
4.4 Control of the operating movements
4.5 Hydraulic supply
4.6 Hoses
Thewiringdiagramisshownhereinsimpliedformtoenablecomprehensionofthefunction.
Pressureisappliedbyahandpump.
Duetothespringforce,thepistonrodretractsagainassoonaspressurestopsbeingapplied
andthepressurecanbereleasedviathesupplyline(notblockedandnopressureapplied).
OnlyLUKAShandpumpsmaybeusedtodrivetheequipment.
If the hand pump is a di󰀨erent make, you must make sure that it complies with LUKAS
specications, otherwise potential dangers may occur, for which LUKAS cannot be held
responsible. Ensure in particular that the authorised operating pressure for LUKAS
equipmentisnotexceeded.
NOTE:
Beforeusingpumpsfromadi󰀨erentmanufacturer,youmustcontactLUKASor
anauthoriseddealer.
ATTENTION!
TheLC99cuttermayonlybeoperatedwithmineraloilinaccordancewithsection
11.1Recommendedhydraulicuids.
Thehandpumpandthecutterareconnectedbyhoselines.
